SW-P01semi-automatic skinning machine is mainly used for flat-end skinning of pipes in the electric heating pipe industry. It is suitable for a variety of pipes such as stainless steel, iron and copper. It has the remarkable characteristics of smooth cuts, no burrs, high efficiency and easy operation and adjustment. It is an indispensable and important equipment in modern production.
Functions
1. Human-machine interface control
SW-P01 is equipped with an intuitive human-machine interface control system, which is easy to operate and allows users to quickly master the use of the equipment. This design greatly reduces the complexity of operation and reduces the requirements for operator skills, so that even novices can quickly get started.
2. Adapt to pipe length
When processing straight pipes, the semi-automatic skinning machine is not limited by the length of the pipe. It can flexibly adapt to pipes of different lengths, enhance the applicability and production efficiency of the equipment, and meet various production needs.
3. Cylinder buffer design
Using cylinder buffer technology, SW-P01 can effectively reduce the impact force during the working process and extend the service life of the equipment. This design not only improves the stability of the equipment, but also reduces the frequency of maintenance and replacement of parts.
4. Adjustable feeding time
The device allows users to set a delay in the feeding time, which ensures that the end face of the pipe is smoother during the peeling process. This function optimizes the peeling quality and makes the surface treatment of the final product more perfect.
5. Production counting function
The built-in production counting function of SW-P01 can record the production quantity in real time and automatically resume counting after power outage or maintenance. This function facilitates management personnel to monitor production and analyze efficiency, helping to optimize production processes.
Technical Specifications
|
Model |
SW-P01 |
|
Power supply |
380V 3P 50HZ 1.5 KW |
|
Air supply |
0.5-0.7MPa |
|
Pipe diameter |
6.0mm - 12mm(Fixture center can be change) |
|
Incoming straightness requirement |
≤5mm/M |
|
Curvature of tube head |
≤0.5mm |
|
output |
About 5000-6000/8h |
|
Size(L*W*H) |
1700*630*970mm |
|
Packing size(L*W*H) |
1800*730*1100mm |
|
Control |
Stepper motor |
|
Weight |
200KG |
How To Order Semi-Automatic Skinning Machine
1. Pipe diameter
Please specify the pipe diameter you need to process so that we can provide you with the appropriate skinning machine configuration.
2. Pipe material
Provide the material information of the pipe to ensure that the equipment can adapt to the processing needs of different materials.
Why Choose SUWAIE
Since 2007, SUWAIE has been committed to providing high-quality heating elements and semi-automatic skinning machines for global HVAC systems. We provide customers with ultra-high-quality products based on the principle of "honoring contracts and providing quality services". OEM & ODM is our strong backing.
