Tpye J Straight Coil Heater
Introduction
Hot runner coil heaters within 20-3000mm is mainly used for hot runner mold as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology. The wire is annealed, with flexibility can be bent into an arc or circle heating. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reuses.
Technology Data
Sheath Material for Coil Heater | Cr Ni-Steel |
Insulation Material | MgO |
Resistance Wire | Ni Cr 80-20 |
Maximum Sheath Temperature | 700°C |
Die Electrical Strength | 1800V A/C |
Insulation | > 5 M W |
Thermocouple | J type (Standard) or K type |
Length Tolerance (Straight) | + 5% |
Wattage Tolerance | + 10% (+ 5% Available Upon Request) |
Resistance Tolerance | + 10% (+ 5% Available Upon Request |
Applications of coil heater
1.Hot Runner & Bushings
2.Tube Extrusion
3.Pipe, rod and tube heating
4.Hot Runner Mould
5.Plastic Injection Machine
6.Plastic Extruder Machine
7.Cutting & sealing bars
8.Medical equipment
9. Semiconductor manufacturing
10.Heat tracing
Coil Heater products picture show
Coil Heater Process show
Hot Runner Mold Heater Test room show
Packing and shipment ways
Why choose US? 1.BUREAU VERITAS AUDITED SUPPLIER
2.Strict confidentiality for customers
3.Have a strong product development capabilities!
4.We have Longterm cooperation forwarders to ensure the quick and safe shipment,
avoid goods delay and extra cost.
5.Solve problems for customers in time
6.Good Payment terms and Reasonable price
7. Excellent after-sales service and feedback
8. Potential problems in product handling 9.we can provide installation video and instructions.
