This Gantry type MgO Powder Filling Machines are specially designed to fill magnesium oxide powder inside of empty tube for tubular heating elements. Comparing with the Single Column Filling Machine, the center guarantee of Gantry type Filling machine is better. If you require high-quality heating elements, we suggest you get the Gantry type Filling machine. The Gantry type Filling machine is for high temperature, small granule MgO powder and the insulation is good.
* Simple operation.
* Automatic machine.
* Two or three layers guide tubes.
* Especially for long tube and big tube diameters.
* Different tube sizes filling in one machine are available.
* Filling speed adjustable.
* Quick changes of tube length and terminal pin outside tube length.
Functions:
* PLC automatically controlled, human-computer interface, the oscillation frequency controlled by electron speed *regulator.
* It adopts jet nozzle which assure almost zero MgO loss.
* Vibrator guarantees the powder density and the density could be above 2.20g/cm3.
* The filling tube moving speed controlled by frequency control.
* Big and small powder box design. Electronic adjustment of the exerted length of terminal pin.
* Indicate how to clear fault automatically.
* 12, 18, 24, 36 and 48 position machines are available to satisfy customers' production requirements.
* Tube diameters below 16mm, tube length below 6000mm. It can be custom-made.
Main technical parameters:
* Power supply: 220V, 50Hz.
* Rated power: 2.0KW.
* Air supply: 5-7kg/cm2.
* Efficiency: 6500pcs/8h (tube length 250mm).
* Feeding speed: 250-300/Min.
|
Element tube length(M) |
Machine size(L*W*H) mm |
Packing Size(L*W*H) mm |
Gross Weight (KG) |
Net Weight (KG) |
|
2.5 |
2000*650m*6900 |
6970*1950*900 |
1110 |
960 |
|
3 |
2000*650m*7900 |
8000*1950*900 |
1290 |
1140 |
|
3.5 |
2000*650m*8900 |
9030*1950*900 |
1470 |
1320 |
|
4 |
2000*650m*9900 |
10060*1950*900 |
1650 |
1500 |
|
4.5 |
2000*650m*10900 |
11090*1950*900 |
1830 |
1680 |
Tubular heater filling machine picture
Our company office
Tubular heating element mgo filling machine packing details
Our Advantages:
1. We accept Custom-made and OEM, so that we can meet the special requirements from different customers.
2. We can produce Moulds/Tooling by ourself, it can help to save your cost and time while in volume production.
3. We have a group of experienced technical engineers to help customers solve the problems and requirements at any time.
4. We promise the high quality with resonable price,and guarantee the lead time for orders.
Quality Control:
1) Technicians self-check in production
2) Engineer spot check in production
3) QC inspects after mass production finished
4) International sales who were trained the technical know-how spot check before shipping
Shipment
FAQ
1. Q: How to handle the complains?
A: 1) During processing, if found any sizes defective, we will inform the clients and get clients approval.
2) If happen any complaints after got the goods, pls show us photos and detail complaints points, we will check with the production department and QC depart. Immediately and give solving solution with 6 hours.
2. Q: How does the Qida control the quality?
A: 1) During processing, the operating machine worker inspect the each sizes by themselves.
2) After finished the first whole part, will show to QA for full inspection.
3) Before shipment, the QA will inspect according to ISO sampling inspection standard for mass production. Will do 100% full checking for small QTY.
4) When shipping the goods, we will attached the inspection report with the parts.
3. Q: What is your term of delivery ?
A: EX-WORKS, FOB, CIF, C&F, DDP, DDU, etc
4. Q: How about the machine payment term&delivery time&Shipping term?
A: Our company payment term accept T/T, Western Union, L/C and so on. Small machine delivery time is 3~7 workdays. Big machine delivery time 15~25 workdays. Shipping term accept EXW, FOB, CIF and so on.
