Insertion Heaters
With premium materials and tight manufacturing controls, Suwaie's cartridge heaters (insertion heaters) provide superior heat transfer, uniform temperatures, resistance to oxidation and corrosion and long life even at high temperatures. Customers benefit from Suwaie's on-time delivery, quality and technical assistance.
It is important to note that allowable watt density depends on the material being heated. For water heating watt densities of several hundred watts per square inch are possible while oil heating may be limited to 5—to 40 watts per square inch.
Replaceable Immersion Insertion Heatersfutures:
1.Clean and safe.
2. Heater never comes into contact with tank contents.
3. Easily replaced without draining the vat or tank.
4. Suwaie immersion cartridge heater contracts when de-energized for easy removal.
5. Stainless-steel sheath accommodates standard diameter flanged Suwaie immersion cartridge heaters from 5" to 72" lengths.
6. Solid Construction. Stainless steel sheath with a welded end cap and NPT fitting that screws into and becomes a permanent part of the tank or vat to be heated
2. Insertion Heaters Specification
Product nama | L Type Cartridge heater |
Cartridge heater diameter | 3mm,4mm,5mm,6mm,8mm,9mm,10mm ,12,14,16,20,22,30mm and so on. |
Resistance wire | NiCr8020 |
Voltage | 220V |
Insulation resistance | ≥500M Ohm |
Leakage current | ≤0.5mA |
Length tolerance | ±0.5mm |
Wattage tolerance | +5%, -10% |
Input voltage | 12V, 24V,110V,220V,240V |
Material | Stainless steel321 tube |
color | White |
3. Insertion Heaters Application
• Semiconductor chamber heating
• Semiconductor wire and die bonding
• Freeze protection and deicing of equipment in cold
climates or applications
• Humidity control
• Patient comfort heating used in medical devices
• Mold die and platen heating
• Seal bars used in packaging equipment
• Test sample heating in gas chromatography equipment
Products show
Product Structure show
Pencil heater process and test working show
Packing and shipment case show
What information should i let you know once i want to make a inquiry?
1.The drawings ( PDF,CAD or 3D )?
2.the voltage, power, shape, tube diameter
3. The surface treatment requirement.
4. How many pieces do you need?
FAQ
1.
Q: Do you have the ability to do independent research and development?
A: Our engineering department has 5 elites, we have the R&D ability to make our products competitive. We also collect regularly customer feedback, products improvement and new product requirement.
2.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 50%-70% T/T in advance (depending on different situations.) ,balance before shipment.
3.
Q:Where is your factory located?How can I wisit there?
A:Our factory is located in shenzhen City, China.
4.
Q: Where are the main markets for sales? A: Mainland China, UK, Thailand, Turkey, Canada, Mexico, Brazil, Argentina, Chile, India, Vietnam, Colombia, Malaysia, Australia, etc.
Shenzhen Suwaie Technology Co., Ltd. Focus on the production of Insertion Heaters. Our company has professional equipment and engineers to provide the production and service of Insertion Heaters.
